Honeywell’s X-DA high-efficiency Class-D power amplifiers are widely used in public address (PA), background music, and voice alarm (VA) systems. To meet different project requirements, Honeywell offers three main series: Standard X-DA, X-DA EN, and X-DA S. Below is a clear comparison table and an easy selection guide to help you choose the right amplifier quickly.
Comparison Table: Honeywell X-DA Amplifier Series
| Feature / Series | Standard X-DA Series | X-DA EN Series | X-DA S Series |
| Models | X-DA1500 / X-DA2250 X-DA4125 / X-DA4060 |
X-DA1500EN / X-DA2250EN X-DA4125EN |
X-DA1500S X-DA2250S |
| Amplifier Type | Class-D, high efficiency | ||
| Output Power | Same rated power per model | ||
| Speaker Line | 70V / 100V | ||
| 24V DC Backup Power | ❌ No | ✅ Yes | ❌ No |
| Voice Alarm (VA) Compliance | ❌ No | ✅ Yes | ❌ No |
| Application Focus | General PA & background music | Emergency & life-safety systems | Basic & cost-effective PA |
| System Reliability Level | Standard | High (with redundancy) | Basic |
| Typical Projects | Offices, hotels, retail, schools | Airports, malls, stations, hospitals | Small PA systems, simple zones |
| Cost Level | Medium | Higher (enhanced features) | Lower |
How to Choose the Right Honeywell X-DA Amplifier (Quick Guide)
Choose X-DA EN Series if you need:
-
A Honeywell voice alarm amplifier
-
24V DC backup power for uninterrupted operation
-
Compliance with VA / emergency broadcasting requirements
-
High reliability for fire alarm and evacuation systems
Choose Standard X-DA Series if you need:
-
A reliable Honeywell PA system amplifier
-
Background music and daily broadcasting
-
Flexible power and channel options
-
No emergency or safety compliance requirement
Choose X-DA S Series if you need:
-
A cost-effective Honeywell power amplifier
-
Simple PA installations
-
Stable mains-powered operation
-
Easy integration with minimal system complexity
Summary
All Honeywell X-DA amplifiers deliver stable performance using high-efficiency Class-D technology. The key difference lies in backup power capability, voice alarm compliance, and system criticality:
-
Standard X-DA Series → General-purpose PA applications
-
X-DA EN Series → Emergency and voice alarm systems with 24V DC backup
-
X-DA S Series → Simple and economical PA solutions
Selecting the right series ensures system reliability, regulatory compliance, and optimal investment for your project.
