X-ND100 Honeywell X-618 Public Address System Digital Noise Detector
Product ID:
X-ND100
Short Description:
Double core shielded cable
Maximum distance up to1000m
Measure broadcast signal and noise signal real time
X-ND100 is an optional accessory for X-618 system. It is used to detect ambient noise, calculate noise sound pressure level, then send data to X-DCS3000. X-DCS3000 will conduct automatic volume control in assigned area, change current sound pressure level of broadcast to improve broadcast clarity.
Main characteristics:
• Connect to DCS by a pair of cables which transmit data and power supply
• Max. 5 noise detectors for each channel
• Real time to measure broadcast signal and noise signal
• The maximum distance is up to1000m
• Flush-mounting in ceiling
• Fire-proof ABS shell
• Ideal for indoor installation
| Parameter | Value |
| Broadcast Signal Input | 100V |
| Sensitivity | -44±3dB (0dB=1V/Pa,1KHz) |
| Frequency Response | 100Hz~20KHz |
| S/N Ratio | ≥58dB |
| Directivity | Omni-directional Directivity |
| Sound Pressure Level | 110dB |
| Power Supply | By DCL bus |
| Color | White (RAL9003) |
| Mounting Hole Size | Φ160mm |
| Depth of Hole | 100mm |
| Ceiling Thickness | 5~25 mm |
| Operating Temperature | -10°C~+55°C |
| Storage Temperature | -25°C~+70°C |
| Relative Humidity | <95%, no condensation |
| Dimensions |
Φ180 x 105 mm
|
| Packing Dimension (W×H×D) | 185 x 185 x115 mm |
| Net Weight |
0.315Kg
|
| Gross Weight |
0.446Kg
|
